微動開關都有哪些型號？
1.小型微動開關:
一般尺寸為長27.8寬10.3高15.9，參數方面又高容量，低負載等不同變化。如V3系列:
Operating Frequency (mechanical).....120 operations / mim |
Operating Frequency (electrical).....All ratings-10~30 operations / mim |
Contact Resistance (initial).....30m Ω (Max.) |
Insulation Resistance (at 500VDC).....100M Ω (Min.) |
Dielectric Strength (50-60Hz).....1000VAC RMS |
Service Life (mechanical).....Min. 5000000 operations |
Service Life (electrical).....Min. 10000 operations |
2.超小型微動開關
一般尺寸為長19.8寬6.4高10.2，功能上有高精度和高壽命的不同性能。如SM系列:
Operating Frequency (mechanical).....120 operations / mim |
Operating Frequency (electrical).....10~30 operations / mim |
Contact Resistance (initial).....300m Ω (Max.) |
Insulation Resistance (at 500VDC).....100M Ω (Min.) |
Dielectric Strength (50-60Hz).....1000VAC RMS |
Service Life (mechanical).....Min. 10000000 operations |
Service Life (electrical).....Min. 6000 operations |
3.超級小型微動開關
一般尺寸為長12.8寬5.8高6.5，這一型中又有特薄型的設計。如DF系列
Operating Frequency (mechanical).....120 operations / mim |
Operating Frequency (electrical).....0.1A-120,3A-10~30 operations / mim |
Contact Resistance (initial).....100m Ω (Max.) |
Insulation Resistance (at 500VDC).....100M Ω (Min.) |
Dielectric Strength (50-60Hz).....1000VAC RMS |
Service Life (mechanical).....Min. 1000000 operations |
Service Life (electrical).....3A-Min. 10000 operations |
4. 防水型
此類產品其防水級別已達到IP67，如SW系列:
Operating Frequency (mechanical).....120 operations / mim |
Operating Frequency (electrical).....10~30 operations / mim |
Contact Resistance (initial).....30m Ω (Max.) |
Insulation Resistance (at 500VDC).....100M Ω (Min.) |
Dielectric Strength (50-60Hz).....1000VAC RMS |
Service Life (mechanical).....Min. 2000000 operations |
Service Life (electrical).....Min. 10000 operations 宏聚電子不斷創新的技術、創造世界最優秀、最具創新性的產品、宏聚開關規范高效的服務---- 提供最專業、最高效的服務，力求客戶滿意宏聚企業。誠信、服務、品質、專業、創新、更多船型開關、帶燈輕觸開關、按鍵開關、金屬按鍵開關、保險絲座、AC電源插座的相關資訊請關注 |
